Single tray

Cross section of a single tray horizontal deodoriser

Why an horizontal deodoriser ?

• the large oil surface exposed to vacuum
• the optimum oil layer and large vapour space optimised by experience
• an efficient steam spraying with a wide steam distribution along the whole length of each level
• no reflux of fatty matter and minimum oil entrainment thanks to a vapour suction on the whole length of each level, giving low vapour velocities at any point
• an easy observation of the process
• minimum supervision and easy operation
• maximum energy recovery via a fully continuous exchange
• minimum steam consumption, 0.5 to 0.8 % sparging steam only which leads to low need in native steam or vacuum unit
